Item
Specification
Valve clearance [Engine cold]
IN: 0.22—0.28 mm {0.0087—0.0110 in}
EX: 0.27—0.33 mm {0.0107—0.0129 in}
Compression
Standard: 1,720 kPa {17.5391 kgf/cm2, 249.465 psi} [300 rpm]
Minimum: 1,204 kPa {12.277 kgf/cm2, 174.58 psi} [300 rpm]
Maximum difference between cylinders: 196.1 kPa {2.0 kgf/cm2, 28.5 psi}
Front oil seal press-in amount
0—1.0 mm {0—0.039 in}
Cylinder Head Bolt Length L
145.2—145.8 mm {5.72—5.74 in}
Cylinder Head Bolt Maximum
146.5 mm {5.77 in}
Oil control valve resistance
6.9—7.9 ohms [20°C {68°F}]
Ignition timing
Approx. BTDC 8 °
Idle speed
No load: 670—770 rpm (MT), 700—800 rpm (AT)
Electrical loads (38—48 A): 00—800 rpm (AT)
Electrical loads (more than 48 A): 800—900 rpm
P/S ON: 700—800 rpm (MT), 750—850 rpm (AT)
A/C ON: 825—925 rpm (MT), 775—875 rpm (AT)
Idle mixture
HC concentration: Within the regulation
CO concentration: Within the regulation
Oil pressure (reference value) [oil temperature: 100 °C {212 °F}]
337—591 kPa {3.44—6.03 kgf/cm2, 49.0—85.8 psi} min [3,000 rpm]
Engine oil capacity (approx. quantity) (AT, 5MT)
Oil replacement: 4.05 L {4.28 US qt, 3.56 Imp qt}
Oil and oil filter replacement: 4.45 L {4.70 US qt, 3.92 Imp qt}
Total (dry engine): 4.75 L {5.02 US qt, 4.18 Imp qt}
Engine oil capacity (approx. quantity) (6MT)
Oil replacement: 4.05 L {4.28 US qt, 3.56 Imp qt}
Oil and oil filter replacement: 4.55 L {4.81 US qt, 4.00 Imp qt}
Total (dry engine): 4.85 L {5.12 US qt, 4.27 Imp qt}
Engine coolant capacity (approx. quantity)
7.5 L {7.9 US qt, 6.6 Imp qt}
Cooling system cap valve opening pressure
93.2—122.6 kPa {0.95—1.25 kgf/cm2, 13.5—17.8 psi}
Thermostat initial-opening temperature
80—84 °C {176—183 °F}
Thermostat full-open temperature
97 °C {207 °F}
Thermostat full-open lift
More than 8.0 mm {0.31 in}
Cooling fan motor current
High: 9.0—12.0 A
Middle: 6.4—9.4 A
Low: 4.8—7.8 A
Fuel line pressure
350—410 kPa {3.57—4.18 kgf/cm2, 50.8—59.4 psi}
Fuel hold pressure
250 kPa {2.55 kgf/cm2, 36.2 psi} or more
Fuel injector resistance
11.4—12.6 ohms [20 °C {68 °F}]
Fuel injector leakage amount
Less than 1 drop/2 min
Fuel injection volume
204—216 ml {204—216 cc, 12.5—13.1 cu in}/min
Battery electrolyte specific gravity [20 °C {68 °F}]
1.22—1.29
Battery load test current
46B24L (36): 135 A
Battery parasitic draw (When the ignition is off (key is removed), all doors and the hood are closed.)
Vehicles with immobilizer system: 25—45 mA
Vehicles without immobilizer system: 30 mA or less
Battery slow charge current
46B24L (36): 3.5—4.5 A
Battery quick charge current [30 min.]
46B24L (36): 25 A
Generator standard voltage [IG-ON]
Terminal B: B+
Terminal P: Approx. 1 V or less
Terminal D: Approx. 0 V
Generator standard voltage [Idle, 20 °C {68 °F}]
Terminal B: 13—15 V
Terminal P: Approx. 3—8 V
Terminal D: Turn the electrical loads (headlights, blower motor, rear window defroster) on and verify that the voltage reading increases.
Generator generated current minimum value
70% of the nominal output current (nominal output current: 100 A)
[ambient temp. 20 °C {68 °F}, voltage 13.0—15.0 V, both engine and generator are hot]
Generator rotor resistance (between slip rings) [20 °C {68 °F}]
2.0—2.3 ohm
Generator brush length
Standard: 22.5 mm {0.89 in}
Minimum: 5.0 mm {0.20 in}
Generator brush spring force
Standard: 4.1—5.3 N {0.42—0.54 kgf, 0.92—1.19 lbf}
Minimum: 1.7 N {0.17 kgf, 0.38 lbf}
Firing order
1-3-4-2 (all cylinders independent firing)
Spark plug type
L3G2 18 110, L3Y1 18 110
Spark plug gap
1.25—1.35 mm {0.050—0.053 in}
Spark plug resistance [25 °C {77 °F}]
3.0—7.5 kilohms
Starter no load test voltage
11 V
Starter no load test current
90 A or less
Starter pinion gap
0.5—2.0 mm {0.02—0.07 in}
Starter armature runout
0.1 mm {0.004 in} max.
Starter commutator diameter
Standard: 29.4 mm {1.16 in}
Minimum: 28.8 mm {1.13 in}
Segment groove depth of starter commutator
Standard: 0.5 mm {0.02 in}
Minimum: 0.2 mm {0.008 in}
Starter brush length
Standard: 12.3 mm {0.48 in}
Minimum: 5.5 mm {0.22 in}
Starter brush spring force
Standard: 15.0—20.4 N {1.53—2.08 kgf, 3.38—4.58 lbf}
Minimum: 2.75 N {0.28 kgf, 0.62 lbf}
